We have multiple measurements for this speaker. Click here to see the default one (which is higher quality if we have one measurement better than the others).
- Quality of the measurement data is high.
- Origin of the data is ErinsAudioCorner.
- Format of the data is generated by a Klippel NFS .
- -3dB (resp. -6db) point v.s. reference is at 90.8Hz (resp. 77.6Hz).
- Reference level is normalised to 0.1dB computed over the frequency range [300.0Hz, 5000.0Hz].
- Frequency deviation is 1.4dB over the same frequency range.
- Directivity
- Horizontal directivity is (-50.0°, 50.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Vertical directivity is (-30.0°, 20.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.33
and would be 7.47 with a
perfect subwoofer.
- Details: NBD: ON 0.389, LW 0.345, SP 0.379, PIR 0.358; SM: SP0.903, PIR0.79; LFQ 1.003, LFX 77Hz
- Tonality (Preference) Score is 5.01
with an EQ and would be 7.89 with a
perfect subwoofer and the same EQ.
- Details: NBD: ON 0.359, LW 0.342, SP 0.394, PIR 0.347; SM: SP0.961, PIR0.923; LFQ 0.849, LFX 67Hz
- Tonality (Preference) Score is 4.33
and would be 7.47 with a
perfect subwoofer.
- Link to original Review: eac review. .
