What we know about the measurement:
- Quality of the measurement data is
medium.
-
Origin of the data is Danley.
-
Format of the data is
a GLL file
.
-
Sensitivity:
-
Sensitivity: 98.0dB (avg. 100Hz-1kHz for 2.83V estimated at 1m).
-
Sensitivity: 78.0dB computed at the measurement distance (10.0m) over the same frequency range.
-
-3dB (resp. -6db) point v.s. reference is at 42.5Hz (resp. 24.0Hz).
-
Reference level is normalised to -0.5dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 14.0dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-30.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-30.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Note: The tonality (Preference) score
does not make sense for toursound speakers. Don't give too much credits
to the value.
- Tonality (Preference) Score is -1.89
and would be -1.07 with a
perfect subwoofer.
- Details:
NBD: ON 1.518,
LW 1.896, SP
2.02, PIR
1.976; SM:
SP0.551,
PIR0.402; LFQ
2.019, LFX 22Hz
- Tonality (Preference) Score is -0.12
with an EQ and would be 0.68 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 1.291,
LW 1.695, SP
1.829, PIR
1.761; SM:
SP0.729,
PIR0.641; LFQ 2.019, LFX 22Hz
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.1dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
47.0 |
2.64 |
2.86 |
| 3 |
121.0 |
2.16 |
1.93 |
| 3 |
1010.0 |
3.0 |
-8.04 |
| 3 |
1046.0 |
1.21 |
2.99 |
| 3 |
2245.0 |
3.0 |
3.0 |
| 3 |
5934.0 |
3.0 |
-5.56 |
| 3 |
11882.0 |
2.99 |
-6.02 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.9dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
-0.25 |
| 3 |
40.0 |
2.14 |
-0.25 |
| 3 |
63.0 |
2.14 |
0.25 |
| 3 |
100.0 |
2.14 |
0.0 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.25 |
| 3 |
1000.0 |
2.14 |
-0.25 |
| 3 |
1600.0 |
2.14 |
0.25 |
| 3 |
2500.0 |
2.14 |
0.75 |
| 3 |
4000.0 |
2.14 |
0.25 |
| 3 |
6300.0 |
2.14 |
0.25 |
| 3 |
10000.0 |
2.14 |
0.25 |
| 3 |
16000.0 |
2.14 |
0.75 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
-0.25 |
| 3 |
31.0 |
4.32 |
-0.25 |
| 3 |
40.0 |
4.32 |
-0.25 |
| 3 |
50.0 |
4.32 |
0.25 |
| 3 |
63.0 |
4.32 |
0.25 |
| 3 |
80.0 |
4.32 |
0.0 |
| 3 |
100.0 |
4.32 |
0.0 |
| 3 |
125.0 |
4.32 |
0.0 |
| 3 |
160.0 |
4.32 |
0.0 |
| 3 |
200.0 |
4.32 |
-0.25 |
| 3 |
250.0 |
4.32 |
-0.25 |
| 3 |
315.0 |
4.32 |
-0.5 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
-0.25 |
| 3 |
630.0 |
4.32 |
-0.5 |
| 3 |
800.0 |
4.32 |
0.75 |
| 3 |
1000.0 |
4.32 |
-0.75 |
| 3 |
1250.0 |
4.32 |
0.0 |
| 3 |
1600.0 |
4.32 |
0.75 |
| 3 |
2000.0 |
4.32 |
1.0 |
| 3 |
2500.0 |
4.32 |
0.75 |
| 3 |
3150.0 |
4.32 |
-0.25 |
| 3 |
4000.0 |
4.32 |
0.25 |
| 3 |
5000.0 |
4.32 |
1.0 |
| 3 |
6300.0 |
4.32 |
0.25 |
| 3 |
8000.0 |
4.32 |
0.25 |
| 3 |
10000.0 |
4.32 |
0.25 |
| 3 |
12000.0 |
4.32 |
-0.25 |
| 3 |
16000.0 |
4.32 |
0.75 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
