What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ErinsAudioCorner.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 23.4Hz (resp. 22.0Hz).
-
Reference level is normalised to -0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 1.8dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 7.23
and would be 7.88 with a
perfect subwoofer.
- Details:
NBD: ON 0.28,
LW 0.246, SP
0.297, PIR
0.253; SM:
SP0.839,
PIR0.714; LFQ
2.571, LFX 20Hz
- Tonality (Preference) Score is 7.96
with an EQ and would be 8.61 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.292,
LW 0.231, SP
0.225, PIR
0.19; SM:
SP0.969,
PIR0.959; LFQ 2.571, LFX 20Hz
-
Link to original Review: eac review.
Links to other reviews: asr review
.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -1.2dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
11704.0 |
0.59 |
-2.19 |
| PK |
44.0 |
0.7 |
-2.13 |
| PK |
1446.0 |
2.42 |
1.26 |
| PK |
408.0 |
3.0 |
-1.19 |
| PK |
85.0 |
2.95 |
-0.75 |
| PK |
2447.0 |
2.97 |
0.76 |
| PK |
745.0 |
2.95 |
-0.75 |
| PK |
218.0 |
2.96 |
-0.75 |
| PK |
6479.0 |
2.85 |
-0.75 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.2dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.0 |
| PK |
40.0 |
2.14 |
-0.25 |
| PK |
63.0 |
2.14 |
-0.25 |
| PK |
100.0 |
2.14 |
0.0 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
-0.25 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
0.25 |
| PK |
2500.0 |
2.14 |
0.0 |
| PK |
4000.0 |
2.14 |
0.0 |
| PK |
6300.0 |
2.14 |
-0.25 |
| PK |
10000.0 |
2.14 |
-0.25 |
| PK |
16000.0 |
2.14 |
-0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.0 |
| PK |
31.0 |
4.32 |
-0.25 |
| PK |
40.0 |
4.32 |
-0.25 |
| PK |
50.0 |
4.32 |
-0.25 |
| PK |
63.0 |
4.32 |
-0.25 |
| PK |
80.0 |
4.32 |
-0.25 |
| PK |
100.0 |
4.32 |
0.0 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
-0.25 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.25 |
| PK |
1600.0 |
4.32 |
0.25 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
0.0 |
| PK |
5000.0 |
4.32 |
0.0 |
| PK |
6300.0 |
4.32 |
-0.25 |
| PK |
8000.0 |
4.32 |
-0.25 |
| PK |
10000.0 |
4.32 |
-0.25 |
| PK |
12000.0 |
4.32 |
-0.25 |
| PK |
16000.0 |
4.32 |
-0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
