What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 83.8dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 63.0Hz (resp. 48.3Hz).
-
Reference level is normalised to -0.5dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.7dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-50.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.94
and would be 7.02 with a
perfect subwoofer.
- Details:
NBD: ON 0.626,
LW 0.449, SP
0.346, PIR
0.329; SM:
SP0.933,
PIR0.811; LFQ
0.62, LFX 43Hz
- Tonality (Preference) Score is 6.39
with an EQ and would be 8.19 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.435,
LW 0.285, SP
0.268, PIR
0.198; SM:
SP0.976,
PIR0.944; LFQ 0.62, LFX 38Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.8dB.
|
| Type |
Freq |
Q |
Gain |
| 5 |
63.0 |
0.76 |
2.18 |
| 3 |
194.0 |
2.07 |
0.72 |
| 3 |
280.0 |
2.4 |
-1.37 |
| 3 |
790.0 |
1.62 |
-1.58 |
| 3 |
1442.0 |
2.77 |
-2.74 |
| 3 |
2014.0 |
0.58 |
0.43 |
| 3 |
2380.0 |
2.74 |
-2.74 |
| 3 |
6276.0 |
2.91 |
-2.76 |
| 5 |
11454.0 |
1.16 |
1.65 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -4.8dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
347.0 |
20.0 |
0.7 |
| 3 |
435.0 |
4.0 |
0.8 |
| 3 |
594.0 |
15.0 |
0.7 |
| 3 |
710.0 |
6.0 |
-0.9 |
| 3 |
925.0 |
5.0 |
-0.5 |
| 3 |
1150.0 |
7.0 |
1.3 |
| 3 |
1275.0 |
16.0 |
-0.8 |
| 3 |
1560.0 |
6.0 |
-1.2 |
| 3 |
1850.0 |
14.0 |
-1.0 |
| 3 |
2090.0 |
13.0 |
-1.9 |
| 3 |
2400.0 |
15.0 |
-1.3 |
| 3 |
2675.0 |
16.0 |
-0.5 |
| 3 |
3350.0 |
3.0 |
2.6 |
| 3 |
4360.0 |
15.0 |
-0.8 |
| 3 |
4980.0 |
3.5 |
2.5 |
| 3 |
8030.0 |
4.0 |
4.4 |
| 3 |
10350.0 |
8.0 |
1.4 |
| 3 |
11380.0 |
7.0 |
-0.7 |
| 3 |
13900.0 |
3.0 |
2.0 |
| 3 |
16100.0 |
2.3 |
4.2 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.5 |
| 3 |
40.0 |
2.14 |
0.5 |
| 3 |
63.0 |
2.14 |
0.5 |
| 3 |
100.0 |
2.14 |
0.25 |
| 3 |
160.0 |
2.14 |
0.25 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
-0.25 |
| 3 |
1600.0 |
2.14 |
-0.25 |
| 3 |
2500.0 |
2.14 |
0.0 |
| 3 |
4000.0 |
2.14 |
0.25 |
| 3 |
6300.0 |
2.14 |
0.0 |
| 3 |
10000.0 |
2.14 |
0.0 |
| 3 |
16000.0 |
2.14 |
0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.9dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.5 |
| 3 |
31.0 |
4.32 |
0.5 |
| 3 |
40.0 |
4.32 |
0.5 |
| 3 |
50.0 |
4.32 |
0.5 |
| 3 |
63.0 |
4.32 |
0.5 |
| 3 |
80.0 |
4.32 |
0.25 |
| 3 |
100.0 |
4.32 |
0.25 |
| 3 |
125.0 |
4.32 |
0.25 |
| 3 |
160.0 |
4.32 |
0.25 |
| 3 |
200.0 |
4.32 |
0.25 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.25 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.0 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
0.0 |
| 3 |
1250.0 |
4.32 |
0.0 |
| 3 |
1600.0 |
4.32 |
-0.25 |
| 3 |
2000.0 |
4.32 |
0.0 |
| 3 |
2500.0 |
4.32 |
0.0 |
| 3 |
3150.0 |
4.32 |
0.25 |
| 3 |
4000.0 |
4.32 |
0.25 |
| 3 |
5000.0 |
4.32 |
0.5 |
| 3 |
6300.0 |
4.32 |
0.25 |
| 3 |
8000.0 |
4.32 |
0.75 |
| 3 |
10000.0 |
4.32 |
0.25 |
| 3 |
12000.0 |
4.32 |
0.25 |
| 3 |
16000.0 |
4.32 |
0.5 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
