What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ErinsAudioCorner.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 84.8dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 52.7Hz (resp. 46.9Hz).
-
Reference level is normalised to -0.2dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.2dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 70.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-30.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 5.25
and would be 7.44 with a
perfect subwoofer.
- Details:
NBD: ON 0.43,
LW 0.393, SP
0.345, PIR
0.33; SM:
SP0.906,
PIR0.785; LFQ
0.786, LFX 46Hz
- Tonality (Preference) Score is 6.26
with an EQ and would be 8.27 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.336,
LW 0.295, SP
0.315, PIR
0.254; SM:
SP0.953,
PIR0.942; LFQ 0.786, LFX 42Hz
-
Link to original Review: eac review.
Links to other reviews: yt review
, asr review
.
-
Vendor specifications:
- Sensitivity 86 dB
- Impedance 6 Ohm
- Size
- Width 207mm
- Height 275mm
- Depth 363 mm)
- Weight 8.2 kg
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.1dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
49.0 |
1.4 |
2.99 |
| PK |
95.0 |
0.91 |
-2.6 |
| PK |
540.0 |
2.93 |
1.29 |
| PK |
849.0 |
2.27 |
-2.66 |
| PK |
942.0 |
2.89 |
2.49 |
| PK |
6144.0 |
2.84 |
-0.95 |
| PK |
12736.0 |
1.15 |
-2.32 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -3.1dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
343.0 |
15.0 |
0.5 |
| PK |
420.0 |
9.0 |
0.6 |
| PK |
491.0 |
12.0 |
0.9 |
| PK |
573.0 |
10.0 |
2.1 |
| PK |
623.0 |
12.0 |
-1.8 |
| PK |
708.0 |
9.0 |
0.5 |
| PK |
798.0 |
8.5 |
-0.9 |
| PK |
915.0 |
4.0 |
-0.9 |
| PK |
1110.0 |
7.0 |
1.4 |
| PK |
1400.0 |
5.5 |
1.8 |
| PK |
1700.0 |
5.5 |
2.2 |
| PK |
1950.0 |
15.0 |
2.1 |
| PK |
2215.0 |
16.0 |
1.5 |
| PK |
2700.0 |
3.5 |
0.9 |
| PK |
3800.0 |
6.0 |
0.8 |
| PK |
6050.0 |
7.0 |
0.3 |
| PK |
7200.0 |
1.1 |
-0.8 |
| PK |
9700.0 |
6.5 |
0.6 |
| PK |
11500.0 |
2.1 |
-0.6 |
| PK |
16000.0 |
2.5 |
0.9 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.6dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.25 |
| PK |
40.0 |
2.14 |
0.25 |
| PK |
63.0 |
2.14 |
0.25 |
| PK |
100.0 |
2.14 |
0.0 |
| PK |
160.0 |
2.14 |
-0.25 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
0.5 |
| PK |
2500.0 |
2.14 |
0.25 |
| PK |
4000.0 |
2.14 |
0.25 |
| PK |
6300.0 |
2.14 |
0.25 |
| PK |
10000.0 |
2.14 |
0.25 |
| PK |
16000.0 |
2.14 |
0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.25 |
| PK |
80.0 |
4.32 |
0.0 |
| PK |
100.0 |
4.32 |
0.0 |
| PK |
125.0 |
4.32 |
-0.25 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
-0.25 |
| PK |
250.0 |
4.32 |
-0.25 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
-0.25 |
| PK |
800.0 |
4.32 |
-0.25 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
0.25 |
| PK |
2000.0 |
4.32 |
0.25 |
| PK |
2500.0 |
4.32 |
0.25 |
| PK |
3150.0 |
4.32 |
0.25 |
| PK |
4000.0 |
4.32 |
0.25 |
| PK |
5000.0 |
4.32 |
0.0 |
| PK |
6300.0 |
4.32 |
0.0 |
| PK |
8000.0 |
4.32 |
0.0 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.0 |
| PK |
16000.0 |
4.32 |
0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
