What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 83.5dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 55.7Hz (resp. 43.9Hz).
-
Reference level is normalised to -0.2dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.8dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-70.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-50.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 5.52
and would be 7.53 with a
perfect subwoofer.
- Details:
NBD: ON 0.453,
LW 0.399, SP
0.336, PIR
0.28; SM:
SP0.882,
PIR0.784; LFQ
0.71, LFX 42Hz
- Tonality (Preference) Score is 6.48
with an EQ and would be 8.35 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.388,
LW 0.33, SP
0.254, PIR
0.182; SM:
SP0.963,
PIR0.942; LFQ 0.71, LFX 39Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| 5 |
62.0 |
1.09 |
3.0 |
| 3 |
181.0 |
2.97 |
0.69 |
| 3 |
354.0 |
1.9 |
0.39 |
| 3 |
646.0 |
1.07 |
-0.7 |
| 3 |
1304.0 |
2.61 |
-2.6 |
| 3 |
1541.0 |
2.86 |
2.87 |
| 3 |
2721.0 |
1.17 |
2.31 |
| 3 |
4492.0 |
2.66 |
-0.51 |
| 3 |
14965.0 |
1.06 |
2.63 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -2.9dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
614.0 |
7.0 |
-1.1 |
| 3 |
826.0 |
3.5 |
-1.1 |
| 3 |
936.0 |
12.0 |
-0.5 |
| 3 |
1310.0 |
4.0 |
-2.2 |
| 3 |
1550.0 |
4.5 |
3.3 |
| 3 |
1744.0 |
15.0 |
-1.0 |
| 3 |
1950.0 |
12.0 |
0.6 |
| 3 |
2293.0 |
11.0 |
2.2 |
| 3 |
2480.0 |
15.0 |
-0.9 |
| 3 |
2735.0 |
9.0 |
2.1 |
| 3 |
3300.0 |
5.0 |
1.8 |
| 3 |
3910.0 |
20.0 |
0.5 |
| 3 |
4430.0 |
18.0 |
-0.4 |
| 3 |
4900.0 |
15.0 |
-0.7 |
| 3 |
5150.0 |
14.0 |
0.7 |
| 3 |
5870.0 |
10.0 |
0.9 |
| 3 |
8780.0 |
7.5 |
0.5 |
| 3 |
10200.0 |
10.0 |
-0.4 |
| 3 |
12680.0 |
3.0 |
-0.5 |
| 3 |
14150.0 |
3.0 |
3.1 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.6dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.5 |
| 3 |
40.0 |
2.14 |
0.5 |
| 3 |
63.0 |
2.14 |
0.25 |
| 3 |
100.0 |
2.14 |
-0.25 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
-0.25 |
| 3 |
1000.0 |
2.14 |
-0.25 |
| 3 |
1600.0 |
2.14 |
0.25 |
| 3 |
2500.0 |
2.14 |
0.0 |
| 3 |
4000.0 |
2.14 |
0.0 |
| 3 |
6300.0 |
2.14 |
-0.25 |
| 3 |
10000.0 |
2.14 |
-0.25 |
| 3 |
16000.0 |
2.14 |
0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.5 |
| 3 |
31.0 |
4.32 |
0.5 |
| 3 |
40.0 |
4.32 |
0.5 |
| 3 |
50.0 |
4.32 |
0.5 |
| 3 |
63.0 |
4.32 |
0.25 |
| 3 |
80.0 |
4.32 |
0.0 |
| 3 |
100.0 |
4.32 |
-0.25 |
| 3 |
125.0 |
4.32 |
0.0 |
| 3 |
160.0 |
4.32 |
0.0 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
-0.25 |
| 3 |
630.0 |
4.32 |
-0.25 |
| 3 |
800.0 |
4.32 |
-0.25 |
| 3 |
1000.0 |
4.32 |
-0.25 |
| 3 |
1250.0 |
4.32 |
-0.25 |
| 3 |
1600.0 |
4.32 |
0.25 |
| 3 |
2000.0 |
4.32 |
0.0 |
| 3 |
2500.0 |
4.32 |
0.0 |
| 3 |
3150.0 |
4.32 |
0.25 |
| 3 |
4000.0 |
4.32 |
0.0 |
| 3 |
5000.0 |
4.32 |
-0.25 |
| 3 |
6300.0 |
4.32 |
-0.25 |
| 3 |
8000.0 |
4.32 |
-0.25 |
| 3 |
10000.0 |
4.32 |
-0.25 |
| 3 |
12000.0 |
4.32 |
0.0 |
| 3 |
16000.0 |
4.32 |
0.25 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
