What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 35.2Hz (resp. 32.2Hz).
-
Reference level is normalised to 0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.7dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-30.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 6.15
and would be 7.47 with a
perfect subwoofer.
- Details:
NBD: ON 0.414,
LW 0.375, SP
0.293, PIR
0.302; SM:
SP0.841,
PIR0.742; LFQ
0.757, LFX 29Hz
- Tonality (Preference) Score is 7.11
with an EQ and would be 8.33 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.325,
LW 0.284, SP
0.238, PIR
0.223; SM:
SP0.934,
PIR0.916; LFQ 0.757, LFX 27Hz
- Link to Original review.
-
Vendor specifications:
- Size
- Width 286mm
- Height 452mm
- Depth 278 mm)
- Weight 14.4 kg
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
29.0 |
1.79 |
2.37 |
| PK |
88.0 |
1.49 |
-1.53 |
| PK |
540.0 |
2.95 |
-0.77 |
| PK |
1954.0 |
2.99 |
2.87 |
| PK |
2964.0 |
1.46 |
-1.07 |
| PK |
4495.0 |
2.1 |
-0.85 |
| PK |
8110.0 |
2.09 |
-1.11 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -2.9dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
401.0 |
18.0 |
0.7 |
| PK |
459.0 |
7.0 |
1.0 |
| PK |
506.0 |
11.0 |
-1.1 |
| PK |
737.0 |
6.0 |
0.9 |
| PK |
907.0 |
5.0 |
-1.5 |
| PK |
1072.0 |
15.0 |
0.7 |
| PK |
1161.0 |
9.0 |
1.2 |
| PK |
1402.0 |
15.0 |
-0.7 |
| PK |
1550.0 |
12.0 |
1.6 |
| PK |
1930.0 |
10.0 |
2.7 |
| PK |
2272.0 |
9.5 |
2.2 |
| PK |
2492.0 |
13.0 |
-2.1 |
| PK |
2720.0 |
18.0 |
1.1 |
| PK |
3020.0 |
6.0 |
-1.3 |
| PK |
3715.0 |
13.0 |
-1.4 |
| PK |
4210.0 |
12.0 |
-0.9 |
| PK |
4880.0 |
7.0 |
-0.7 |
| PK |
7900.0 |
2.5 |
-1.0 |
| PK |
11700.0 |
2.0 |
0.9 |
| PK |
16450.0 |
1.6 |
-1.1 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.6dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.25 |
| PK |
40.0 |
2.14 |
0.0 |
| PK |
63.0 |
2.14 |
-0.25 |
| PK |
100.0 |
2.14 |
-0.25 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
0.5 |
| PK |
2500.0 |
2.14 |
0.25 |
| PK |
4000.0 |
2.14 |
0.0 |
| PK |
6300.0 |
2.14 |
0.0 |
| PK |
10000.0 |
2.14 |
0.0 |
| PK |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.6dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.0 |
| PK |
50.0 |
4.32 |
0.0 |
| PK |
63.0 |
4.32 |
-0.25 |
| PK |
80.0 |
4.32 |
-0.25 |
| PK |
100.0 |
4.32 |
-0.25 |
| PK |
125.0 |
4.32 |
-0.25 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.25 |
| PK |
1600.0 |
4.32 |
0.25 |
| PK |
2000.0 |
4.32 |
0.5 |
| PK |
2500.0 |
4.32 |
0.25 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
0.0 |
| PK |
5000.0 |
4.32 |
0.0 |
| PK |
6300.0 |
4.32 |
0.0 |
| PK |
8000.0 |
4.32 |
0.0 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.0 |
| PK |
16000.0 |
4.32 |
0.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
