What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 88.5dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 79.1Hz (resp. 64.5Hz).
-
Reference level is normalised to -0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.1dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-70.0°, 70.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.76
and would be 7.55 with a
perfect subwoofer.
- Details:
NBD: ON 0.453,
LW 0.403, SP
0.328, PIR
0.324; SM:
SP0.906,
PIR0.849; LFQ
1.385, LFX 64Hz
- Tonality (Preference) Score is 5.7
with an EQ and would be 8.21 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.38,
LW 0.301, SP
0.278, PIR
0.235; SM:
SP0.957,
PIR0.941; LFQ 1.385, LFX 55Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
84.0 |
0.67 |
2.97 |
| PK |
378.0 |
2.14 |
-1.15 |
| PK |
714.0 |
0.65 |
1.61 |
| PK |
1394.0 |
1.36 |
-2.64 |
| PK |
1884.0 |
2.54 |
1.65 |
| PK |
2461.0 |
2.58 |
-2.98 |
| PK |
3216.0 |
0.34 |
2.41 |
| PK |
4645.0 |
2.93 |
-1.97 |
| PK |
9372.0 |
1.28 |
-0.85 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -1.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
325.0 |
18.0 |
-1.1 |
| PK |
370.0 |
13.0 |
-1.0 |
| PK |
410.0 |
13.0 |
0.5 |
| PK |
513.0 |
15.0 |
1.5 |
| PK |
580.0 |
12.0 |
0.9 |
| PK |
654.0 |
15.0 |
1.6 |
| PK |
860.0 |
5.0 |
1.2 |
| PK |
1220.0 |
9.5 |
-0.8 |
| PK |
1385.0 |
12.0 |
0.5 |
| PK |
1928.0 |
12.0 |
1.4 |
| PK |
2085.0 |
20.0 |
-0.9 |
| PK |
2420.0 |
8.5 |
-3.0 |
| PK |
2930.0 |
6.0 |
-0.4 |
| PK |
3720.0 |
9.0 |
1.3 |
| PK |
4830.0 |
6.0 |
-1.1 |
| PK |
5760.0 |
6.0 |
1.6 |
| PK |
7510.0 |
11.0 |
0.8 |
| PK |
8550.0 |
10.0 |
-0.8 |
| PK |
10680.0 |
5.0 |
-1.1 |
| PK |
14450.0 |
2.4 |
1.6 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.1dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.75 |
| PK |
40.0 |
2.14 |
0.75 |
| PK |
63.0 |
2.14 |
0.75 |
| PK |
100.0 |
2.14 |
0.25 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.25 |
| PK |
400.0 |
2.14 |
0.25 |
| PK |
630.0 |
2.14 |
0.5 |
| PK |
1000.0 |
2.14 |
0.25 |
| PK |
1600.0 |
2.14 |
0.25 |
| PK |
2500.0 |
2.14 |
0.0 |
| PK |
4000.0 |
2.14 |
0.25 |
| PK |
6300.0 |
2.14 |
0.25 |
| PK |
10000.0 |
2.14 |
0.0 |
| PK |
16000.0 |
2.14 |
0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.25 |
| PK |
80.0 |
4.32 |
0.25 |
| PK |
100.0 |
4.32 |
0.0 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.25 |
| PK |
630.0 |
4.32 |
0.25 |
| PK |
800.0 |
4.32 |
0.25 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
-0.25 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
0.25 |
| PK |
5000.0 |
4.32 |
0.0 |
| PK |
6300.0 |
4.32 |
0.25 |
| PK |
8000.0 |
4.32 |
0.0 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.25 |
| PK |
16000.0 |
4.32 |
0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
