We have multiple measurements for this speaker. Click here to see the default one (which is higher quality if we have one measurement better than the others).
- Quality of the measurement data is high.
- Origin of the data is ASR.
- Format of the data is generated by a Klippel NFS .
- -3dB (resp. -6db) point v.s. reference is at 68.8Hz (resp. 41.0Hz).
- Reference level is normalised to -0.2dB computed over the frequency range [300.0Hz, 5000.0Hz].
- Frequency deviation is 2.6dB over the same frequency range.
- Directivity
- Horizontal directivity is (-40.0°, 40.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Vertical directivity is (-50.0°, 50.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 5.57
and would be 7.45 with a
perfect subwoofer.
- Details: NBD: ON 0.465, LW 0.391, SP 0.367, PIR 0.36; SM: SP0.93, PIR0.864; LFQ 0.723, LFX 39Hz
- Tonality (Preference) Score is 6.38
with an EQ and would be 8.11 with a
perfect subwoofer and the same EQ.
- Details: NBD: ON 0.364, LW 0.298, SP 0.3, PIR 0.28; SM: SP0.972, PIR0.939; LFQ 0.723, LFX 36Hz
- Tonality (Preference) Score is 5.57
and would be 7.45 with a
perfect subwoofer.
- Horizontal measurement
- Link to Original review.
