What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 55.7Hz (resp. 51.3Hz).
-
Reference level is normalised to -0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.6dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-70.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.53
and would be 5.89 with a
perfect subwoofer.
- Details:
NBD: ON 0.566,
LW 0.502, SP
0.419, PIR
0.439; SM:
SP0.67,
PIR0.403; LFQ
0.651, LFX 51Hz
- Tonality (Preference) Score is 5.45
with an EQ and would be 7.59 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.459,
LW 0.395, SP
0.373, PIR
0.343; SM:
SP0.936,
PIR0.897; LFQ 0.561, LFX 45Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.9dB.
|
| Type |
Freq |
Q |
Gain |
| 5 |
55.0 |
1.09 |
2.96 |
| 3 |
143.0 |
2.55 |
0.81 |
| 3 |
221.0 |
1.74 |
1.37 |
| 3 |
547.0 |
2.48 |
-0.73 |
| 3 |
1103.0 |
2.16 |
1.15 |
| 3 |
2545.0 |
2.66 |
2.26 |
| 3 |
5490.0 |
0.82 |
-2.38 |
| 3 |
8478.0 |
2.89 |
-2.52 |
| 4 |
12246.0 |
30.0 |
-1.45 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -1.9dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
564.0 |
8.0 |
-1.6 |
| 3 |
689.0 |
9.0 |
-3.6 |
| 3 |
755.0 |
9.0 |
1.4 |
| 3 |
1128.0 |
8.0 |
1.4 |
| 3 |
1390.0 |
7.0 |
-1.8 |
| 3 |
1550.0 |
11.0 |
1.6 |
| 3 |
1917.0 |
16.0 |
1.2 |
| 3 |
2280.0 |
15.0 |
0.9 |
| 3 |
2675.0 |
15.0 |
2.0 |
| 3 |
2965.0 |
12.0 |
-0.7 |
| 3 |
3270.0 |
15.0 |
0.9 |
| 3 |
3700.0 |
13.0 |
-1.6 |
| 3 |
4250.0 |
10.0 |
-1.3 |
| 3 |
5650.0 |
7.0 |
-1.0 |
| 3 |
6630.0 |
3.0 |
-1.2 |
| 3 |
8505.0 |
4.0 |
-3.1 |
| 3 |
9470.0 |
11.0 |
1.1 |
| 3 |
10790.0 |
5.0 |
2.1 |
| 3 |
12760.0 |
5.0 |
-2.6 |
| 3 |
16450.0 |
6.0 |
-1.0 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.25 |
| 3 |
40.0 |
2.14 |
0.25 |
| 3 |
63.0 |
2.14 |
0.25 |
| 3 |
100.0 |
2.14 |
0.0 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
-0.25 |
| 3 |
630.0 |
2.14 |
-0.25 |
| 3 |
1000.0 |
2.14 |
0.0 |
| 3 |
1600.0 |
2.14 |
0.0 |
| 3 |
2500.0 |
2.14 |
0.0 |
| 3 |
4000.0 |
2.14 |
-0.5 |
| 3 |
6300.0 |
2.14 |
-0.5 |
| 3 |
10000.0 |
2.14 |
-0.5 |
| 3 |
16000.0 |
2.14 |
-0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.25 |
| 3 |
31.0 |
4.32 |
0.25 |
| 3 |
40.0 |
4.32 |
0.25 |
| 3 |
50.0 |
4.32 |
0.25 |
| 3 |
63.0 |
4.32 |
0.25 |
| 3 |
80.0 |
4.32 |
0.0 |
| 3 |
100.0 |
4.32 |
0.0 |
| 3 |
125.0 |
4.32 |
0.0 |
| 3 |
160.0 |
4.32 |
0.0 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
-0.25 |
| 3 |
500.0 |
4.32 |
-0.25 |
| 3 |
630.0 |
4.32 |
-0.25 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
0.0 |
| 3 |
1250.0 |
4.32 |
0.0 |
| 3 |
1600.0 |
4.32 |
0.0 |
| 3 |
2000.0 |
4.32 |
0.0 |
| 3 |
2500.0 |
4.32 |
0.25 |
| 3 |
3150.0 |
4.32 |
-0.25 |
| 3 |
4000.0 |
4.32 |
-0.25 |
| 3 |
5000.0 |
4.32 |
-0.5 |
| 3 |
6300.0 |
4.32 |
-0.5 |
| 3 |
8000.0 |
4.32 |
-0.75 |
| 3 |
10000.0 |
4.32 |
-0.25 |
| 3 |
12000.0 |
4.32 |
-0.5 |
| 3 |
16000.0 |
4.32 |
-0.25 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
