What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 43.9Hz (resp. 41.0Hz).
-
Reference level is normalised to 0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.9dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-30.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 5.1
and would be 7.05 with a
perfect subwoofer.
- Details:
NBD: ON 0.508,
LW 0.47, SP
0.344, PIR
0.367; SM:
SP0.903,
PIR0.747; LFQ
0.83, LFX 41Hz
- Tonality (Preference) Score is 6.02
with an EQ and would be 7.83 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.426,
LW 0.389, SP
0.284, PIR
0.297; SM:
SP0.947,
PIR0.906; LFQ 0.83, LFX 38Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.4dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
37.0 |
2.96 |
2.99 |
| 3 |
74.0 |
1.18 |
1.86 |
| 3 |
689.0 |
2.61 |
1.9 |
| 3 |
1760.0 |
2.9 |
-1.63 |
| 3 |
2406.0 |
2.95 |
-0.88 |
| 3 |
7308.0 |
1.03 |
-0.81 |
| 3 |
15150.0 |
1.98 |
-2.38 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -2.5dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
347.0 |
14.0 |
-0.5 |
| 3 |
432.0 |
6.0 |
0.7 |
| 3 |
667.0 |
10.0 |
2.0 |
| 3 |
736.0 |
12.0 |
-1.4 |
| 3 |
870.0 |
3.5 |
4.7 |
| 3 |
895.0 |
25.0 |
1.6 |
| 3 |
950.0 |
5.5 |
-5.9 |
| 3 |
1060.0 |
13.0 |
-1.0 |
| 3 |
1148.0 |
7.0 |
1.7 |
| 3 |
1350.0 |
6.0 |
-1.0 |
| 3 |
1742.0 |
7.0 |
-2.5 |
| 3 |
2050.0 |
9.0 |
-1.3 |
| 3 |
2477.0 |
11.0 |
-2.0 |
| 3 |
2715.0 |
15.0 |
1.4 |
| 3 |
3680.0 |
10.0 |
-0.7 |
| 3 |
3930.0 |
20.0 |
0.9 |
| 3 |
4520.0 |
11.0 |
0.8 |
| 3 |
7170.0 |
0.8 |
-0.5 |
| 3 |
11120.0 |
2.5 |
0.9 |
| 3 |
15180.0 |
1.7 |
-1.6 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.75 |
| 3 |
40.0 |
2.14 |
0.75 |
| 3 |
63.0 |
2.14 |
0.5 |
| 3 |
100.0 |
2.14 |
0.25 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.25 |
| 3 |
1000.0 |
2.14 |
-0.5 |
| 3 |
1600.0 |
2.14 |
-0.25 |
| 3 |
2500.0 |
2.14 |
-0.5 |
| 3 |
4000.0 |
2.14 |
0.0 |
| 3 |
6300.0 |
2.14 |
-0.25 |
| 3 |
10000.0 |
2.14 |
0.0 |
| 3 |
16000.0 |
2.14 |
-0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.1dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.75 |
| 3 |
31.0 |
4.32 |
0.75 |
| 3 |
40.0 |
4.32 |
0.75 |
| 3 |
50.0 |
4.32 |
0.25 |
| 3 |
63.0 |
4.32 |
0.5 |
| 3 |
80.0 |
4.32 |
0.5 |
| 3 |
100.0 |
4.32 |
0.25 |
| 3 |
125.0 |
4.32 |
0.0 |
| 3 |
160.0 |
4.32 |
0.0 |
| 3 |
200.0 |
4.32 |
0.25 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.25 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.25 |
| 3 |
800.0 |
4.32 |
0.5 |
| 3 |
1000.0 |
4.32 |
-0.5 |
| 3 |
1250.0 |
4.32 |
0.0 |
| 3 |
1600.0 |
4.32 |
-0.25 |
| 3 |
2000.0 |
4.32 |
-0.5 |
| 3 |
2500.0 |
4.32 |
-0.5 |
| 3 |
3150.0 |
4.32 |
0.0 |
| 3 |
4000.0 |
4.32 |
0.0 |
| 3 |
5000.0 |
4.32 |
0.0 |
| 3 |
6300.0 |
4.32 |
0.0 |
| 3 |
8000.0 |
4.32 |
0.0 |
| 3 |
10000.0 |
4.32 |
0.0 |
| 3 |
12000.0 |
4.32 |
0.0 |
| 3 |
16000.0 |
4.32 |
-0.25 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
