What we know about the measurement:
Quality of the measurement data is
high .
Origin of the data is ASR.
Format of the data is
generated by a Klippel NFS
.
-3dB (resp. -6db) point v.s. reference is at 48.3Hz (resp. 43.9Hz).
Reference level is normalised to -0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
Frequency deviation is 3.9dB over the same frequency range.
Directivity
Horizontal directivity
is (-60.0°, 60.0° )
between 1kHz and 10kHz. Angle computed for +/-6dB.
Vertical directivity
is (-20.0°, 20.0° )
between 1kHz and 10kHz. Angle computed for +/-6dB.
Tonality (Preference) Score
Tonality (Preference) Score is 5.15
and would be 7.16 with a
perfect subwoofer.
Details:
NBD: ON 0.485,
LW 0.423, SP
0.456, PIR
0.422; SM:
SP0.903,
PIR0.843; LFQ
0.657, LFX 42Hz
Tonality (Preference) Score is 6.17
with an EQ and would be 8.04 with a
perfect subwoofer and the same EQ.
Details:
NBD: ON 0.352,
LW 0.307, SP
0.339, PIR
0.283; SM:
SP0.951,
PIR0.901; LFQ 0.657, LFX 39Hz
Link to original Review: asr review .
.
AutomaticEQ (IIR)
Set preamp gain to: -3.2dB .
Type
Freq
Q
Gain
5
66.0
0.76
2.98
3
66.0
2.8
-2.9
3
117.0
1.49
-1.39
3
668.0
2.97
-2.03
3
1491.0
2.95
2.43
3
2302.0
1.73
2.9
3
2909.0
2.68
-1.27
3
7173.0
2.77
1.23
3
13092.0
1.2
2.95
Download
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
amirm@ASR (IIR)
Set preamp gain to: -0.0dB .
Type
Freq
Q
Gain
3
630.0
4.0
-3.5
3
3030.0
2.0
-2.0
3
9100.0
4.0
-2.0
Download
maiky76@ASR LW (IIR)
Set preamp gain to: -2.8dB .
Type
Freq
Q
Gain
3
64.51
3.27
-1.53
3
117.71
1.55
-1.47
3
645.12
4.13
-3.11
3
922.0
2.14
-1.55
3
1799.79
0.82
2.5
3
2979.36
4.75
-1.86
3
12256.79
0.55
2.94
3
9514.76
4.14
-1.8
Download
These EQ is designed by ASR member maiky76. These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
maiky76@ASR (IIR)
Set preamp gain to: -2.6dB .
Type
Freq
Q
Gain
3
63.5
4.13
-1.48
3
117.21
1.21
-1.51
3
625.78
4.98
-2.9
3
932.0
1.81
-2.0
3
1665.6
1.14
2.96
3
2929.12
5.0
-1.46
3
12251.29
0.71
2.18
3
9511.76
3.17
-1.65
Download
These EQ is designed by ASR member maiky76. These EQ optimise the Harman score and is a good start for far field listening like in your living room.
Graphic EQ 15 bands
Set preamp gain to: -0.5dB .
Type
Freq
Q
Gain
3
25.0
2.14
0.25
3
40.0
2.14
0.25
3
63.0
2.14
-0.25
3
100.0
2.14
-0.25
3
160.0
2.14
-0.25
3
250.0
2.14
0.0
3
400.0
2.14
0.0
3
630.0
2.14
-0.5
3
1000.0
2.14
0.0
3
1600.0
2.14
0.5
3
2500.0
2.14
0.25
3
4000.0
2.14
0.0
3
6300.0
2.14
0.0
3
10000.0
2.14
0.0
3
16000.0
2.14
0.0
Download
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
Set preamp gain to: -0.6dB .
Type
Freq
Q
Gain
3
20.0
4.32
0.0
3
25.0
4.32
0.25
3
31.0
4.32
0.25
3
40.0
4.32
0.25
3
50.0
4.32
0.0
3
63.0
4.32
-0.25
3
80.0
4.32
-0.25
3
100.0
4.32
-0.25
3
125.0
4.32
-0.25
3
160.0
4.32
-0.25
3
200.0
4.32
-0.25
3
250.0
4.32
0.0
3
315.0
4.32
0.0
3
400.0
4.32
0.0
3
500.0
4.32
0.0
3
630.0
4.32
-0.5
3
800.0
4.32
-0.25
3
1000.0
4.32
0.0
3
1250.0
4.32
0.25
3
1600.0
4.32
0.5
3
2000.0
4.32
0.25
3
2500.0
4.32
0.25
3
3150.0
4.32
0.0
3
4000.0
4.32
0.0
3
5000.0
4.32
0.0
3
6300.0
4.32
0.0
3
8000.0
4.32
0.0
3
10000.0
4.32
0.0
3
12000.0
4.32
0.25
3
16000.0
4.32
0.0
3
20000.0
4.32
0.0
Download
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
