What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 80.5dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 98.1Hz (resp. 50.5Hz).
-
Reference level is normalised to 0.3dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.8dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-70.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-30.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.49
and would be 6.77 with a
perfect subwoofer.
- Details:
NBD: ON 0.44,
LW 0.432, SP
0.505, PIR
0.401; SM:
SP0.757,
PIR0.597; LFQ
0.25, LFX 49Hz
- Tonality (Preference) Score is 6.49
with an EQ and would be 8.63 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.276,
LW 0.239, SP
0.288, PIR
0.184; SM:
SP0.921,
PIR0.944; LFQ 0.304, LFX 45Hz
-
Link to original Review: asr review.
.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.9dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
98.0 |
1.15 |
2.09 |
| PK |
98.0 |
1.76 |
2.1 |
| PK |
214.0 |
1.18 |
-2.06 |
| PK |
604.0 |
1.44 |
2.48 |
| PK |
903.0 |
2.39 |
-1.06 |
| PK |
2082.0 |
2.25 |
2.1 |
| PK |
3008.0 |
1.2 |
-1.37 |
| PK |
4803.0 |
2.56 |
-1.23 |
| NO |
8766.0 |
30.0 |
0.46 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -2.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
358.0 |
7.0 |
0.4 |
| PK |
457.0 |
4.0 |
1.4 |
| PK |
523.0 |
13.0 |
0.8 |
| PK |
575.0 |
8.0 |
2.1 |
| PK |
652.0 |
11.0 |
1.7 |
| PK |
736.0 |
12.0 |
0.9 |
| PK |
808.0 |
7.0 |
0.8 |
| PK |
1105.0 |
11.0 |
0.5 |
| PK |
1422.0 |
8.0 |
0.8 |
| PK |
1713.0 |
6.0 |
1.2 |
| PK |
1970.0 |
10.0 |
1.7 |
| PK |
2220.0 |
8.5 |
1.9 |
| PK |
2530.0 |
10.0 |
0.6 |
| PK |
3220.0 |
11.0 |
-0.7 |
| PK |
5156.0 |
1.503 |
-3.0 |
| PK |
5732.0 |
5.0 |
1.0 |
| PK |
8146.0 |
5.0 |
2.7 |
| PK |
8571.0 |
5.0 |
-3.6 |
| PK |
12970.0 |
10.0 |
-0.8 |
| PK |
15630.0 |
8.0 |
-1.2 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.5 |
| PK |
100.0 |
2.14 |
0.5 |
| PK |
160.0 |
2.14 |
-0.25 |
| PK |
250.0 |
2.14 |
-0.25 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.25 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
0.25 |
| PK |
2500.0 |
2.14 |
0.25 |
| PK |
4000.0 |
2.14 |
-0.25 |
| PK |
6300.0 |
2.14 |
-0.25 |
| PK |
10000.0 |
2.14 |
0.0 |
| PK |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.5 |
| PK |
31.0 |
4.32 |
0.5 |
| PK |
40.0 |
4.32 |
0.5 |
| PK |
50.0 |
4.32 |
0.5 |
| PK |
63.0 |
4.32 |
0.5 |
| PK |
80.0 |
4.32 |
0.5 |
| PK |
100.0 |
4.32 |
0.5 |
| PK |
125.0 |
4.32 |
0.25 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
-0.25 |
| PK |
250.0 |
4.32 |
-0.25 |
| PK |
315.0 |
4.32 |
-0.25 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.25 |
| PK |
630.0 |
4.32 |
0.25 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
-0.25 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
-0.25 |
| PK |
3150.0 |
4.32 |
-0.5 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.25 |
| PK |
6300.0 |
4.32 |
0.0 |
| PK |
8000.0 |
4.32 |
0.0 |
| PK |
10000.0 |
4.32 |
-0.25 |
| PK |
12000.0 |
4.32 |
0.0 |
| PK |
16000.0 |
4.32 |
-0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
