What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 35.2Hz (resp. 32.2Hz).
-
Reference level is normalised to 0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.2dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-30.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 6.1
and would be 7.6 with a
perfect subwoofer.
- Details:
NBD: ON 0.365,
LW 0.338, SP
0.347, PIR
0.317; SM:
SP0.91,
PIR0.766; LFQ
0.822, LFX 32Hz
- Tonality (Preference) Score is 7.17
with an EQ and would be 8.39 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.317,
LW 0.246, SP
0.284, PIR
0.229; SM:
SP0.966,
PIR0.943; LFQ 0.822, LFX 27Hz
- Link to Original review.
-
Vendor specifications:
- SPL
- max: 108 dB
- peak: 116 dB
- pink_noise: 93 dB
- Size
- Width 383mm
- Height 253mm
- Depth 292 mm)
- Weight 13.0 kg
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
28.0 |
1.93 |
2.98 |
| 3 |
85.0 |
2.15 |
2.03 |
| 3 |
1333.0 |
2.94 |
-2.07 |
| 3 |
1480.0 |
2.87 |
2.45 |
| 3 |
4654.0 |
2.81 |
-1.55 |
| 3 |
9001.0 |
1.42 |
-0.79 |
| 3 |
13652.0 |
1.13 |
-1.45 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -2.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
656.0 |
19.0 |
1.3 |
| 3 |
795.0 |
10.0 |
1.0 |
| 3 |
980.0 |
4.0 |
-0.7 |
| 3 |
1300.0 |
9.0 |
-0.6 |
| 3 |
1560.0 |
6.5 |
2.4 |
| 3 |
1710.0 |
9.0 |
-1.3 |
| 3 |
1915.0 |
12.0 |
1.2 |
| 3 |
2130.0 |
8.0 |
-0.8 |
| 3 |
2285.0 |
18.0 |
1.1 |
| 3 |
2510.0 |
9.2 |
-1.5 |
| 3 |
2740.0 |
17.0 |
1.0 |
| 3 |
3020.0 |
8.0 |
-1.0 |
| 3 |
3380.0 |
10.0 |
0.5 |
| 3 |
4260.0 |
8.5 |
-1.2 |
| 3 |
4870.0 |
10.5 |
-1.6 |
| 3 |
5510.0 |
10.0 |
-0.5 |
| 3 |
7290.0 |
3.0 |
-0.6 |
| 3 |
9500.0 |
2.0 |
-0.4 |
| 3 |
12500.0 |
1.7 |
-1.1 |
| 3 |
16200.0 |
3.2 |
-1.5 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.6dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.5 |
| 3 |
40.0 |
2.14 |
0.25 |
| 3 |
63.0 |
2.14 |
0.25 |
| 3 |
100.0 |
2.14 |
0.25 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
-0.25 |
| 3 |
1600.0 |
2.14 |
0.25 |
| 3 |
2500.0 |
2.14 |
-0.25 |
| 3 |
4000.0 |
2.14 |
-0.25 |
| 3 |
6300.0 |
2.14 |
-0.25 |
| 3 |
10000.0 |
2.14 |
-0.25 |
| 3 |
16000.0 |
2.14 |
-0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.25 |
| 3 |
31.0 |
4.32 |
0.25 |
| 3 |
40.0 |
4.32 |
0.25 |
| 3 |
50.0 |
4.32 |
0.0 |
| 3 |
63.0 |
4.32 |
0.0 |
| 3 |
80.0 |
4.32 |
0.0 |
| 3 |
100.0 |
4.32 |
0.0 |
| 3 |
125.0 |
4.32 |
0.0 |
| 3 |
160.0 |
4.32 |
-0.25 |
| 3 |
200.0 |
4.32 |
-0.25 |
| 3 |
250.0 |
4.32 |
-0.25 |
| 3 |
315.0 |
4.32 |
-0.25 |
| 3 |
400.0 |
4.32 |
-0.25 |
| 3 |
500.0 |
4.32 |
-0.25 |
| 3 |
630.0 |
4.32 |
0.0 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
-0.25 |
| 3 |
1250.0 |
4.32 |
-0.25 |
| 3 |
1600.0 |
4.32 |
0.0 |
| 3 |
2000.0 |
4.32 |
0.0 |
| 3 |
2500.0 |
4.32 |
-0.25 |
| 3 |
3150.0 |
4.32 |
-0.25 |
| 3 |
4000.0 |
4.32 |
-0.25 |
| 3 |
5000.0 |
4.32 |
-0.5 |
| 3 |
6300.0 |
4.32 |
-0.25 |
| 3 |
8000.0 |
4.32 |
-0.5 |
| 3 |
10000.0 |
4.32 |
-0.5 |
| 3 |
12000.0 |
4.32 |
-0.5 |
| 3 |
16000.0 |
4.32 |
-0.5 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
