What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 85.1dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 58.6Hz (resp. 52.7Hz).
-
Reference level is normalised to -0.2dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.8dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-10.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.63
and would be 6.0 with a
perfect subwoofer.
- Details:
NBD: ON 0.486,
LW 0.365, SP
0.356, PIR
0.333; SM:
SP0.626,
PIR0.226; LFQ
0.477, LFX 51Hz
- Tonality (Preference) Score is 5.95
with an EQ and would be 8.14 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.391,
LW 0.293, SP
0.322, PIR
0.246; SM:
SP0.956,
PIR0.937; LFQ 0.604, LFX 46Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
46.0 |
2.65 |
2.99 |
| 3 |
67.0 |
2.42 |
0.94 |
| 3 |
92.0 |
2.91 |
1.62 |
| 3 |
849.0 |
2.94 |
-2.28 |
| 3 |
3177.0 |
0.84 |
2.34 |
| 3 |
6361.0 |
0.75 |
-4.04 |
| 3 |
15150.0 |
1.82 |
-7.99 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -1.5dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
322.0 |
10.0 |
0.8 |
| 3 |
361.0 |
4.0 |
-0.5 |
| 3 |
415.0 |
8.0 |
0.4 |
| 3 |
488.0 |
7.0 |
0.6 |
| 3 |
635.0 |
10.0 |
-1.0 |
| 3 |
768.0 |
15.0 |
-0.9 |
| 3 |
899.0 |
2.4 |
-3.0 |
| 3 |
1175.0 |
8.0 |
1.4 |
| 3 |
1414.0 |
10.0 |
-0.9 |
| 3 |
1562.0 |
10.0 |
2.3 |
| 3 |
1726.0 |
12.0 |
-1.6 |
| 3 |
2085.0 |
17.0 |
-1.6 |
| 3 |
2295.0 |
10.0 |
1.5 |
| 3 |
2482.0 |
20.0 |
-1.1 |
| 3 |
2710.0 |
12.0 |
1.4 |
| 3 |
3365.0 |
5.0 |
1.6 |
| 3 |
4430.0 |
11.0 |
0.8 |
| 3 |
7500.0 |
0.9 |
-3.5 |
| 3 |
15100.0 |
1.7 |
-6.0 |
| 0 |
16500.0 |
0.7071067811865475 |
0.0 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.25 |
| 3 |
40.0 |
2.14 |
0.25 |
| 3 |
63.0 |
2.14 |
0.25 |
| 3 |
100.0 |
2.14 |
0.25 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
-0.25 |
| 3 |
1000.0 |
2.14 |
-0.25 |
| 3 |
1600.0 |
2.14 |
0.25 |
| 3 |
2500.0 |
2.14 |
0.0 |
| 3 |
4000.0 |
2.14 |
0.0 |
| 3 |
6300.0 |
2.14 |
-0.5 |
| 3 |
10000.0 |
2.14 |
-0.5 |
| 3 |
16000.0 |
2.14 |
-1.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.25 |
| 3 |
31.0 |
4.32 |
0.25 |
| 3 |
40.0 |
4.32 |
0.25 |
| 3 |
50.0 |
4.32 |
0.25 |
| 3 |
63.0 |
4.32 |
0.25 |
| 3 |
80.0 |
4.32 |
0.25 |
| 3 |
100.0 |
4.32 |
0.0 |
| 3 |
125.0 |
4.32 |
0.0 |
| 3 |
160.0 |
4.32 |
-0.25 |
| 3 |
200.0 |
4.32 |
-0.25 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
-0.25 |
| 3 |
800.0 |
4.32 |
-0.25 |
| 3 |
1000.0 |
4.32 |
-0.25 |
| 3 |
1250.0 |
4.32 |
0.0 |
| 3 |
1600.0 |
4.32 |
0.0 |
| 3 |
2000.0 |
4.32 |
0.0 |
| 3 |
2500.0 |
4.32 |
0.0 |
| 3 |
3150.0 |
4.32 |
0.0 |
| 3 |
4000.0 |
4.32 |
0.0 |
| 3 |
5000.0 |
4.32 |
-0.25 |
| 3 |
6300.0 |
4.32 |
-0.5 |
| 3 |
8000.0 |
4.32 |
-0.5 |
| 3 |
10000.0 |
4.32 |
-0.5 |
| 3 |
12000.0 |
4.32 |
-0.75 |
| 3 |
16000.0 |
4.32 |
-0.75 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
