What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 84.8dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 63.0Hz (resp. 55.7Hz).
-
Reference level is normalised to 0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.1dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-30.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 5.82
and would be 8.24 with a
perfect subwoofer.
- Details:
NBD: ON 0.368,
LW 0.246, SP
0.263, PIR
0.209; SM:
SP0.944,
PIR0.907; LFQ
0.481, LFX 52Hz
- Tonality (Preference) Score is 6.41
with an EQ and would be 8.61 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.297,
LW 0.186, SP
0.276, PIR
0.194; SM:
SP0.968,
PIR0.97; LFQ 0.626, LFX 46Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.9dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
47.0 |
2.12 |
2.99 |
| PK |
102.0 |
2.01 |
-0.84 |
| PK |
289.0 |
0.97 |
0.82 |
| PK |
1954.0 |
2.76 |
-1.05 |
| PK |
2670.0 |
2.95 |
0.96 |
| PK |
4654.0 |
1.45 |
-1.98 |
| PK |
7834.0 |
2.96 |
0.61 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -0.6dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
382.0 |
18.0 |
-0.4 |
| PK |
445.0 |
5.0 |
0.8 |
| PK |
505.0 |
5.0 |
-1.0 |
| PK |
604.0 |
7.0 |
1.1 |
| PK |
660.0 |
10.0 |
-0.8 |
| PK |
917.0 |
3.0 |
-0.4 |
| PK |
1540.0 |
15.0 |
-0.4 |
| PK |
1650.0 |
10.0 |
0.5 |
| PK |
1760.0 |
15.0 |
-0.5 |
| PK |
2000.0 |
15.0 |
-0.4 |
| PK |
2361.0 |
1.0 |
-0.9 |
| PK |
2451.0 |
20.0 |
-0.4 |
| PK |
2555.0 |
22.0 |
0.9 |
| PK |
3300.0 |
5.0 |
-0.3 |
| PK |
4894.0 |
1.482 |
-2.1 |
| PK |
4950.0 |
18.0 |
0.6 |
| PK |
5650.0 |
6.0 |
-0.4 |
| PK |
8050.0 |
4.0 |
0.5 |
| PK |
10515.0 |
1.0 |
-0.8 |
| PK |
13800.0 |
1.7 |
-0.4 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.25 |
| PK |
40.0 |
2.14 |
0.25 |
| PK |
63.0 |
2.14 |
0.25 |
| PK |
100.0 |
2.14 |
-0.25 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
0.0 |
| PK |
2500.0 |
2.14 |
0.0 |
| PK |
4000.0 |
2.14 |
-0.25 |
| PK |
6300.0 |
2.14 |
-0.25 |
| PK |
10000.0 |
2.14 |
0.0 |
| PK |
16000.0 |
2.14 |
0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.25 |
| PK |
80.0 |
4.32 |
-0.25 |
| PK |
100.0 |
4.32 |
-0.25 |
| PK |
125.0 |
4.32 |
-0.25 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.25 |
| PK |
6300.0 |
4.32 |
0.0 |
| PK |
8000.0 |
4.32 |
0.0 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.0 |
| PK |
16000.0 |
4.32 |
0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
