What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 87.8dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 20.5Hz (resp. 71.8Hz).
-
Reference level is normalised to 0.8dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 6.3dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-10.0°, 10.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 1.46
and would be 4.34 with a
perfect subwoofer.
- Details:
NBD: ON 0.751,
LW 0.722, SP
0.644, PIR
0.661; SM:
SP0.747,
PIR0.219; LFQ
1.213, LFX 67Hz
- Tonality (Preference) Score is 4.59
with an EQ and would be 6.32 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.645,
LW 0.639, SP
0.636, PIR
0.614; SM:
SP0.943,
PIR0.899; LFQ 1.061, LFX 36Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -9.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
22.0 |
0.26 |
3.0 |
| 3 |
26.0 |
0.4 |
3.0 |
| 3 |
31.0 |
0.42 |
3.0 |
| 3 |
299.0 |
0.88 |
3.0 |
| 3 |
3405.0 |
2.69 |
-2.53 |
| 3 |
4989.0 |
1.54 |
-4.16 |
| 3 |
12736.0 |
2.58 |
-6.0 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -0.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
342.0 |
5.0 |
0.6 |
| 3 |
432.0 |
5.0 |
-1.7 |
| 3 |
575.0 |
5.0 |
-3.6 |
| 3 |
620.0 |
5.0 |
12.0 |
| 3 |
644.0 |
5.0 |
-11.4 |
| 3 |
747.0 |
5.0 |
12.0 |
| 3 |
762.0 |
5.0 |
-13.0 |
| 3 |
1031.0 |
5.0 |
2.4 |
| 3 |
1080.0 |
1.645 |
-5.7 |
| 3 |
1552.0 |
5.0 |
-2.6 |
| 3 |
1958.0 |
5.0 |
2.5 |
| 3 |
2213.0 |
1.753 |
-3.9 |
| 3 |
2823.0 |
5.0 |
10.2 |
| 3 |
2950.0 |
5.0 |
-15.8 |
| 3 |
3714.0 |
5.0 |
-10.6 |
| 3 |
3742.0 |
2.221 |
12.0 |
| 3 |
4647.0 |
2.399 |
-10.3 |
| 3 |
6157.0 |
4.98 |
-3.7 |
| 3 |
10413.0 |
5.0 |
-1.7 |
| 3 |
12919.0 |
2.253 |
-6.9 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -2.6dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
2.25 |
| 3 |
40.0 |
2.14 |
1.5 |
| 3 |
63.0 |
2.14 |
0.75 |
| 3 |
100.0 |
2.14 |
0.25 |
| 3 |
160.0 |
2.14 |
0.25 |
| 3 |
250.0 |
2.14 |
0.25 |
| 3 |
400.0 |
2.14 |
0.25 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
-0.25 |
| 3 |
1600.0 |
2.14 |
-0.25 |
| 3 |
2500.0 |
2.14 |
-0.25 |
| 3 |
4000.0 |
2.14 |
-0.25 |
| 3 |
6300.0 |
2.14 |
-0.25 |
| 3 |
10000.0 |
2.14 |
0.0 |
| 3 |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -2.8dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
2.25 |
| 3 |
31.0 |
4.32 |
1.75 |
| 3 |
40.0 |
4.32 |
1.5 |
| 3 |
50.0 |
4.32 |
1.0 |
| 3 |
63.0 |
4.32 |
0.75 |
| 3 |
80.0 |
4.32 |
0.25 |
| 3 |
100.0 |
4.32 |
0.25 |
| 3 |
125.0 |
4.32 |
0.25 |
| 3 |
160.0 |
4.32 |
0.25 |
| 3 |
200.0 |
4.32 |
0.25 |
| 3 |
250.0 |
4.32 |
0.25 |
| 3 |
315.0 |
4.32 |
0.25 |
| 3 |
400.0 |
4.32 |
0.25 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.0 |
| 3 |
800.0 |
4.32 |
-0.25 |
| 3 |
1000.0 |
4.32 |
-0.25 |
| 3 |
1250.0 |
4.32 |
-0.5 |
| 3 |
1600.0 |
4.32 |
-0.25 |
| 3 |
2000.0 |
4.32 |
0.0 |
| 3 |
2500.0 |
4.32 |
-0.25 |
| 3 |
3150.0 |
4.32 |
-0.25 |
| 3 |
4000.0 |
4.32 |
-0.25 |
| 3 |
5000.0 |
4.32 |
-0.5 |
| 3 |
6300.0 |
4.32 |
-0.25 |
| 3 |
8000.0 |
4.32 |
0.0 |
| 3 |
10000.0 |
4.32 |
0.0 |
| 3 |
12000.0 |
4.32 |
-0.25 |
| 3 |
16000.0 |
4.32 |
0.0 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
